<?xml version="1.0" encoding="Shift_JIS"?> <scriptrunner> <connection> <credential> <accesskey>AKIAIDWXMMTS4L4IXXXXX</accesskey> <secretkey>eukotvrxG/7KTT79yAb+Ya0SBVnILxxxxxxxxxx</accesskey> </credential> <region>ap-northeast-1</region> <requestqueuename>runner_sqs_ixxxxx_req</requestqueuename> <receivequeuename>runner_sqs_ixxxxx_recv</receivequeuename> <description>Execute from ScriptRunner for Amazon SQS.</description> <user>root</user> <password>password</password> </connection> <params> <param project="root@project" script="script"> <input key="var">value</input> <option key="TYPE">production</option> <option key="ENABLE_TYPE_SWITCH">false</option> <option key="ENABLE_XML_LOG">true</option> <option key="LOG_LEVEL">FINFO</option> </param> </params> </scriptrunner> |
Element | Attribute | Required/Optional | Description | Remarks |
---|---|---|---|---|
scriptrunner | - | Required | ||
connection | - | Required | Writes one connection information to scriptrunner element. | |
credential | - | Required | Writes one Amazon Web Services credential information to scriptrunner element. | |
accesskey | - | Required | Writes one Amazon Web Services access key to credential element. | |
secretkey | - | Required | Writes one Amazon Web Services secret key to credential element. | |
encrypt | Optional | Shows whether the contents(secret key) of secretkey element is encrypted or not.
Uses secret key after decryption to communication with Amazon Web Services despite encrypt settings. However, whole communication with Amazon Web Services will be encrypted by HTTPS. For how to encrypt secret key specified with plain text, refer to "Secret key and password encryption of start setting file". |
||
requestqueuename | - | Required | Specify the queue name of script execution request storing queue. Then, writes one to connection element. | receivequeuename | - | Required | Specify the queue name of script execution result storing queue. Then, writes one to connection element. | region | - | Required | Writes the region that belongs to the queue specified in requestqueuename/receivequeuename. Then, writes one to connection element.
Region you can specify is as follows.
|
receivetimeout | - | Optional | Specify the time(second) to wait when receiving script execution result. If you omit, sets 3600(1 hour). | |
description | - | Optional | Specify the session information when the ScriptRunner for Amazon SQS was executed. The specified information is the contents showed in Control panel "Task Manager"-[Session]tab-[Description] page. | |
user | - | Required | User executing script | |
password | - | Required | Password of user executing script | |
encrypt | Optional | Shows whether password element contents(password) is encrypted or not.
Uses secret key after decryption to communication with Amazon Web Services despite encrypt settings. However, whole communication with Amazon Web Services will be encrypted by HTTPS. For how to encrypt secret key specified with plain text, refer to "Secret key and password encryption of start setting file". |
||
params | - | Required | ||
param | - | Required | Setup start script. one param corresponds to one starting script. | In ScriptRunner for Amazon SQS, only one param element can be specified within params.|
project | Required | Specify service name. Default service name format is <Creator>@<Project name>. | ||
script | Required | Specify script name. | ||
input | - | Optional | Setup argument delivering to script. Multiple input can be specified in param element. | |
key | Required | Name of argument delivering to script. It is required to be the same name as the argument name setup in script. | ||
option | - | Optional | Option delivering to script. Multiple option can be specified in param element.
For details on options, refer to "Option". |
|
key | Required | Key of option |
Type of script variable | Default value | Remarks |
---|---|---|
Character string type | Empty character | |
Whole number type | 0 |
|
Decimal degit type | 0 |
|
Date/Time type | 1970-01-01T09:00:00.000+0900 | |
True false value type | false | |
Binary type | null | |
XML type | Empty type |
Key | Value | Description | Remarks |
---|---|---|---|
TYPE | - | Specifies Classification when executing. | |
default | Executes with "default" classification. Even if TYPE is not specified, executes with "default". |
||
test | Executes with "For test" classification. | ||
production | Executes with "For production" classification. | ||
<User specification type> | When enrolling service, executes with classification specified with user when creating global resource. | ||
ENABLE_TYPE_SWITCH | - | If the global resource of specified type does not exist, setup ON/OFF whether to re-search by changing the classification. | |
true | If the global resource of specified type does not exist, re-search with "default" classification. | ||
false | Errors, if the global resource of specified type does not exist. If ENABLE_TYPE_SWITCH is omitted, operates as "false". |
||
ENABLE_XML_LOG | - | Sets ON/OFF of XML log | |
true | Outputs XML log | ||
false | Does not output XML log(Established value) | ||
LOG_LEVEL | - | Sets log level. | |
NOTICE | Log level that outputs only important logs(Established value) | ||
INFO | Log level that is recommended when operating | ||
FINFO | Log level that is recommended when developing | ||
FINEST | Log level that outputs more detailed logs | ||
DEBUG | Log level that outputs well detailed logs |
<?xml version="1.0" encoding="Shift_JIS"?> <scriptrunner> <connection> <credential> <accesskey>%{1}</accesskey> <secretkey>%{2}</accesskey> </credential> <region>ap-northeast-1</region> <requestqueuename>runner_sqs_ixxxxx_req</requestqueuename> <receivequeuename>runner_sqs_ixxxxx_recv</receivequeuename> <description>Executes ScriptRunner for Amazon SQS.</description> <user>root</user> <password>password</password> </connection> <params> <param project="root@project" script="%{3}"> <input key="var">%{4}</input> <option key="TYPE">production</option> <option key="ENABLE_TYPE_SWITCH">false</option> <option key="ENABLE_XML_LOG">true</option> <option key="LOG_LEVEL">FINFO</option> </param> </params> </scriptrunner> |
Key | Description | Remarks |
---|---|---|
AWS_ACCESS_KEY | Access key of Amazon Web Services. |
|
AWS_SECRET_KEY | Secret key of Amazon Web Services. |
|
REQUEST_QUEUE_NAME | Queue name of script execution request storing queue. |
|
RECEIVE_QUEUE_NAME | Specifies queue name of script execution result storing queue. |
|
AWS_REGION | Region that queue specified in REQUEST_QUEUE_NAME / RECEIVE_QUEUE_NAME belongs to. |
|
RECEIVE_TIMEOUT | Time (second) that waits receiving of script execution result. |
|
ENCRYPTED | Sets [true] if AWS_SECRET_KEY is encrypted and saved. |
AWS_ACCESS_KEY=AKIAIDWXMMTS4xxxxxxx AWS_SECRET_KEY=eukotvrxG/7KTT79yAb+Ya0SBVnILxxxxxxx AWS_REGION=ap-northeast-1 REQUEST_QUEUE_NAME=runner_on_demand_ixxxxx_req RECEIVE_QUEUE_NAME=runner_on_demand_ixxxxx_recv RECEIVE_TIMEOUT=3600 |
> ScriptRunnerSQS.exe scriptrunnersqs.xml \" \" |
