| Location | Type |
|---|---|
| The first input handler | Numeric |
| The second input handler | Numeric |
| Logic output | Numeric |
Refer to "Logic Specifications" for details.
| Category | Property | Description |
|---|---|---|
| Precision | Specify precision | Select whether to directly specify the decimal places of precision in decimal type calculation. |
| Precision | Specified digits | Directly specifies the number of decimal places in decimal type precision. |
| Precision | Rounding | Specify the method of rounding. |
| Null processing | Null option | Specify how to handle the input if it contains null. |
| Comment | Comment | The comment will also be output to the specifications.It does not affect the conversion process. |
| Option | Description |
|---|---|
| Convert null into 0 | Converts null to 0 and continue with the process. |
| Throw exception when unable to determine/calculate/process | Throws exception (CalculationException) when unable to determine/calculate/process. |
| Output null if any input is null | Outputs null if the value of any input handler is null. |
Refer to "Logic Specifications" for details.
| Property | Setting |
|---|---|
| Specify precision | Not Checked |
| Specified digits | |
| Rounding | Round to 0. |
| Null option | Convert null into 0 |
| 10,3 |
| 10,3.0 |
| 10.0,3 |
| 1 |
| 1.0 |
| 1.0 |
